Engineering Change Notification - NHD-C160100DiZ-FSW-FBW: 4/23/26
This notice on April 23rd, is to inform you of the change to the following LCD:
- NHD-C160100DiZ-FSW-FBW
Based on considerable feedback from customers, the display FPC has been redesigned to add the following features:
- Internal pull-up added to set COMSCN = HIGH as the default configuration.
- Pin #1 changed from NC to COMSCN so that users can change the display output direction.
| When COMSCN = “L”; COM0 → COMX | When COMSCN = “H”; COMX → COM0 |
|---|---|
The new displays will be labeled with a different revision control number after the part number. See example below.
| Old Design | New Design |
To inquire about how this may affect your open orders, please contact your account manager. To purchase a sample of the new version, please contact us at nhsales@newhavendisplay.com
To request a datasheet for the new version, please contact us at nhtech@newhavendisplay.com.
