Engineering Change Notification - NHD-COG14-36: 9/22/25
This notice on September 22nd, is to inform you of the change to the following product:
- NHD-COG14-36
This breakout PCB has been redesigned to add support for additional connection types. The board now supports 1.27mm, 1.5mm, and 2.0mm pitch SMT and thru-hole connections also.
This design improvement has led to an increased overall size of the PCB.
The new board will be labeled with a different revision control number after the part number. See example below.
OLD Design |
NEW Design |
We understand that every customer’s application is unique, and therefore recommend you test and validate samples of the updated design. Samples may be purchased by contacting us at nhsales@newhavendisplay.com. When ordering samples, please specify that you would like to receive the new version.
