Engineering Change Notification - NHD-2.8-240320AF-CSXP-F: 07/16/25
This notice on July 16th, is to inform you of the change to the following TFT LCD products:
- NHD-2.8-240320AF-CSXP-F
- NHD-2.8-240320AF-CSXP-FT
- NHD-2.8-240320AF-CSXP-FCTP
These displays have been redesigned to add support for 3/4-wire SPI interface, increase display brightness, and add EMI shielding as design improvements. Complete details regarding the pinout change, interface selection, and backlight characteristics can be found in the Product Transition Guide.
The new displays will be labeled with a different revision control number after the part number. See example below.
OLD Design |
NEW Design |
We understand that every customer’s application is unique, and therefore recommend you test and validate samples of the updated design. Samples may be purchased by contacting us at nhsales@newhavendisplay.com. When ordering samples, please specify that you would like to receive the new version.
