Engineering Change Notification - NHD-5.0-800480AF-ASXP: 11/21/24
This notice on November 21st, is to inform you of the change to the following TFT display products:
- NHD-5.0-800480AF-ASXP
- NHD-5.0-800480AF-ASXP-CTP
- NHD-5.0-800480FT-CSXP
- NHD-5.0-800480FT-CSXP-CTP
- NHD-5.0-HDMI-N-RSXP
- NHD-5.0-HDMI-N-RSXP-CTU
The display’s internal structure has been modified for better insulation between the TFT glass and bezel to maintain consistent performance and enhance durability under mechanical stress.
The change described above should not have any impact on the part’s electrical or mechanical compatibility within your system. All of our testing has found the new version to be compatible with existing platforms driving the old display. We fully expect the new displays to fit and function without any issue for our customers.
The new displays will be labeled with a different revision control number on the back. See example below.
OLD Design |
NEW Design |
We understand that every customer’s application is unique, and therefore recommend you test and validate samples of the updated design. Samples may be purchased by contacting us at nhsales@newhavendisplay.com. When ordering samples, please specify that you would like to receive the new version.
