Engineering Change Notification - NHD-7.0-1024600AF-LSXP: 8/22/24
This notice on August 22nd, is to inform you of the change to the following TFT products:
- NHD-7.0-1024600AF-LSXP
- NHD-7.0-1024600AF-LSXP-CTP
- NHD-7.0-1024600AF-LSXP-CTPAT
- NHD-7.0-1024600AF-LSXP-CTPET
- NHD-7.0-1024600MB-LSXP-CTP
- NHD-7.0-HDMI-HR-RSXP
- NHD-7.0-HDMI-HR-RSXP-CTU
- NHD-7.0-HDMI-HR-RSXP-NB
The display FPC has been redesigned to make the TFT control signals inactive when the user enables standby mode. As a result, the display will appear normally black rather than normally white in standby mode while the backlight is ON. There are no changes to the FPC dimensions or pinout.
The changes described above should not have any impact on the part’s electrical or mechanical compatibility within your system. All our testing has found the new display to be compatible with existing platforms driving the old display. We fully expect the new display to fit and function without any issue for our customers.
The new displays will be labeled with a different revision control number after the part number. See example below.
OLD Design |
NEW Design |
We understand that every customer’s application is unique, and therefore recommend you test and validate samples of the updated design. Samples may be purchased by contacting us at nhsales@newhavendisplay.com. When ordering samples, please specify that you would like to receive the new version.
